UE-340

UE-320 UHF DUAL CHANNEL WIRELESS MICROPHONE

THIS RECEIVER ADOPTS HIGH EFFICIENCY AND LOW CONSUMPTION RF EMISSION AND  PLL TECHNOLOGY , WHICH MAKES PRODUCT MORE STABILITY AND CONSISTENCY REACH THE PEAK AND EACH SYSTEM HAS EXCELLENT ELECTRICAL PERFORMANCE.

FEATURES:

◆ ENHANCED SQUELCH DIGITAL SUPPRESSION CIRCUIT, STANDBY WITHOUT NOISE OUTPUT.

◆ WIDE RANGE OF FREQUENCY RESPONSE, ULTRA-LOW DISTORTION.

◆ WITH PERFECT SWITCH NOISE ELIMINATION CIRCUIT, PROTECTION SYSTEM EQUIPMENT.

◆ THE UNIFORM DIRECTIVITY OF THE HEART SHAPE CAN EFFECTIVELY ENHANCE THE MAIN SOUND SOURCE, WHILE MINIMIZING THE NOISE.

◆ HIGH EFFICIENCY FILTERING STEEL FOR BLAST NOISE AND BLAST NOISE WITH BALL IN LAUNCHING SYSTEM.

◆ AUDIO FREQUENCY COMPRESSION AND EXPANSION TECHNOLOGY, LESS NOISE, LARGE DNAMIC RANGE.

◆ MULTIPLE OUTPUT CIRCUIT DESIGN, STABLE RECEPTION, STACKING WITHOUT INTERFERENCE.

◆ SUITABLE FOR LARGE AND MEDIUM-SIZED STAGE, KARAOKE HALL, FAMILY ENTERTAINMENT AND OTHER OCCASIONS.

RECEIVER SPECIFICATIONS:

◆ FREQUENCY RANGE: 600MHZ-800MHZ

◆ MODULATION MODE: WIDEBAND FM

◆ FREQUENCY STABILITY: ±0.005%

◆ DYNAMIC RANGE: 100DB

◆ MAXIMUM DEVIATION: ±45KHZ

◆ AUDIO FREQUENCY RESPONSE: 80HK—15KHZ（±3DB）

◆ ADJACENT CHANNEL INHIBITION: >50DB

◆ WORKING ENVIRONMENT TEMPERATURE: -10℃—+40℃

◆ RECEIVER MODE: SUPERHETERODYNE OF SECONDARY FREQUENCY CONVERSION

◆ IF:FRIST: 110MHZ,SECOND: 10.7MHZ

◆ WIRELESS INTERFACE: BNC/50Ω

◆ SPURIOUS SUPPRESSION: ≥75DB

◆ MAXIMUN OUTPUT LEVEL: +10DBV

TRANSMITTERS SPECIFICATIONS:

H06 METAL HANDHELD MICROPHONE

◆ USE ALUMINUM ALLOY DESIGN, MORE COMFORTABLE

◆ ANTENNA:HANDHELD MICROPHONE BUILT-IN SPIRAL ANTENNA,BODY PACKBY A QUARTER WAVE TRANSMITTER PREHENSIBLE BULLWHIP SHAPPED ANTENNA.

◆ OUTPUT POWER: 30MW

◆ SPURIOUS SUPPRESSION: -60DB

◆ 2 AA ALKALINE BATTERIES

◆ OPERATING TIME: 8 HOURS(WHILE OUTPUT IS 30MW)

H07 PLASTIC HANDHELD MICROPHONE:

◆ PLASTIC HANDLHELD DESIGN,MORE DURABLE.

◆ ANTENNA: HANDHELD MICROPHONE BUILT-IN SPIRAL ANTENNA,BODY PACK BY A QUARTER WAVE TRANSMITTER PREHENSIBLE BULLWHIP

    SHAPPED ANTENNA.

◆ OUTPUT POWER: 30MW

◆ SPURIOUS SUPPRESSION: -60DB

◆ 2 AA ALKALINE BATTERIES

◆ OPERATING TIME: 8 HOURS(WHILE OUTPUT IS 30MW)
