NX-7800MT Video Tracking Conference System

DIGITAL VIDEO WIRED CONFERENCE SYSTEM MAIN UNIT NX-7800M

 FEATURES:

• THE SYSTEM HOST INTEGRATES CONFERENCE DISCUSSION AND AUTOMATIC VIDEO TRACKING FUNCTIONS;

• 19-INCH STANDARD CABINET CAN BE INSTALLED, AND THE SYSTEM HAS AUTOMATIC MEMORY FUNCTION WHEN POWER OFF;

• THE STURDY ALUMINUM ALLOY HAS A BEAUTIFUL AND DURABLE APPEARANCE, WHICH CAN REALIZE AUTOMATIC CAMERA TRACKING FUNCTION;

• THE CONNECTION BETWEEN THE SYSTEM HOST AND THE CAMERA ADOPTS RS232/RS485 COMMUNICATION PROTOCOL;

• UP TO 6 CAMERAS CAN BE CONFIGURED

• RECORDING FUNCTION, ALL THE PROCESSES OF CAN BE RECORDED AND SAVED WITH USB RECORDING INTERFACE

• THE SYSTEM HOST HAS A VOICE CONTROL TO OPEN THE MICROPHONE FUNCTION

• WITH CHINESE AND ENGLISH LCD MENU DISPLAY SCREEN, THE CONFERENCE FUNCTION MENU SETTING CAN BE REALIZED THROUGH FUNCTION KEYS;

• FOUR-WAY UNIT PORTS, EACH OF WHICH HAS UP TO 30 REPRESENTATIVE UNITS;

• A VARIETY OF CONFERENCE MODES CAN BE REALIZED

1: FULLY OPEN DISCUSSION MODE, (FREE) THE NUMBER OF OPEN UNITS AT THE SAME TIME IS NOT LIMITED

2: AUTOMATIC MODE, (AUTOMATIC) THE NUMBER OF SPEAKING UNITS IS ADJUSTABLE 1/2/3/4/5/6.

TURN ON THE MICROPHONE AND TURN OFF THE EARLIEST CHAIRMAN'S MICROPHONE TO SPEAK;

3: CHAIRMAN MODE: (C.ONLY) ONLY THE CHAIRMAN MICROPHONE IS ALLOWED TO SPEAK

• WITH RECEIVING AND SENDING CENTRAL CONTROL CODES, IT CAN BE LINKED WITH THE CENTRAL CONTROL SYSTEM TO CONTROL ALL FUNCTIONS OF THE CONFERENCE HOST AND OTHER MULTIPLE TRIGGERS.

Specification:

INPUT AND OUTPUT: 8P-DIN×4

INPUT: RCA×1

OUTPUT: XLRM×1 (BALANCED) RCA×2 6.35MM×1

WORKING VOLTAGE: AC220V-50HZ

POWER LOSS: 120W (MAX)

FREQUENCY RESPONSE: 20HZ-20KHZ

EXTERNAL DIMENSIONS: 480×310×90MM

WEIGHT: 5.85KG

COLOUR: BLACK
