NX-2288S

CHARACTERISTICS:

THE WIRELESS CONFERENCE SYSTEM CAN SUPPORT 1-255 CHAIRMEN UNIT

AND DELEGATE UNIT.YOU JUST NEED TO ADD THE CONFERENCE UNIT WITHOUT

ADD MAIN UNIT WHEN YOU INCREASE THE NUMBER OF PEOPLE IN MEETING.

IT SUPPORTS THE FIFO MODE AND HAVE TWO MODE,CHAIRMEN AND LIMIT

MODES.THIS SYSTEM HAS 4 CHANNELS WHICH SUPPORTS 1-4 MICROPHONE

-S CAN BE TURNED ON AT THE SAME TIME.

RECEIVER FEATURES:

◆ EASY AND CONVENIENT TO INSTALL

◆ SIMPLE FUNCTION OPERATION TO SETTING IN ONE-KEY

◆ AUTOMATIC FREQUENCY TRACKING AND LOCKING FUNCTION

◆ BUILT-IN 60 WIFI COMMUNICATE CHANNELS, MULTI-MACHINE SIMULTANEOUS USE WITHOUT INTERFERENCE

◆ BUILT-IN 520 SPEECH CHANNELS,COMPLETELY AVOID INTERFERENCE

◆ BUILT-IN MODERATE HOWLING INHIBITION FUNCTION, WHICH CAN EFFECTIVELY

   REDUCE THE HOWLING

◆ BUILT-IN ADVANCED SWEEPING ALGORITHM.SCAN THE OPERATING ENVIRON MENT AND AUTOMATICALLY SELECT

    THE FREQUENCY WITHOUT INTERFERENCE

◆ BUILT-IN ADVANCED ENCRYPTION COMMUNICATION ALGORITHM, COMPLETELY ELIMINATE COMMUNICATION ERRORS

   AND MISOPERATION

◆ BUILT-IN POWER MONITORING FUNCTION.CONFERENCE STAND SHOWS BATTERY LEVEL

◆ BUILT-IN CHAIRMAN PRIORITY FUNCTION

◆ CONTROL OF INTELLIGENT SPEECH RIGHTS.SUPPORT 4 PEOPLE TO SPEAK AT THE SAME TIME,SUPPORT UP TO 99 PEOPLE FIFO

◆ THE CONFERENCE UNIT HAS THE FUNCTION OF AUTOMATIC CLOSING.THE CONFERENCE UNIT WILL SHUT DOWN AUTOMATICALLY

   AFTER THE MAIN UNIT HAS BEEN DISCONNECTED FOR MORE THAN 30 SECONDS

SCOPE OF APPLICATION:

◆ OFFICE CONFERENCE ROOM

◆ BANK /HOTEL CONFERENCE ROOM

◆ SCHOOL RADIO, CONFERENCE, ART PERFORMANCE HOST, ETC

◆ FOLK ORCHESTRA, OUTDOOR PERFORMANCE

◆ WEDDING PROGRAM HOST

◆ RADIO PROGRAMS TO ANSWER, DISCUSS, ETC

◆ TV PROGRAM PERFORMANCE, GUEST COMMENTS, ETC

RECEIVER SPECIFICATION:

◆ RECEIVER WORKING VOLTAGE: DC--12V-14V 2A

◆ OPERATING CURRENT: 600MAH

◆ POWER CONSUMPTION:5W

◆ RECEIVE SENSITIVITY:-105DB

◆ OUTPUT VOLTAGE:1V

◆ RECEIVING DISTANCE:60-80 METER

◆ FREQUENCY RESPONSE:50HZ-15KHZ

◆ FREQUENCY STABILITY: ± 0.001%

◆ S/N:>100DB

◆ THD:<0.01%< SPAN="">

UNIT SPECIFICATION:

◆ FREQUENCY INTERFERENCE REJECTION: >60DB

◆ POLARS PATTERN: CARDIOID

◆ SENSITIVITY:>20DBM(1V)

◆ TRANSMITTING POWER: >10DBM(10MW)

◆ POWER CONSUMPTION:120MAH

◆ FREQUENCY RANGE:612-692MHZ OR 715---785MHZ
